电脱盐防爆变压器

Explosion-proof Desalting Transformer

电脱盐防爆变压器
交直流

本产品作为电脱盐成套设备的核心部件,具备稳定可靠的供电能力,确保原油脱盐脱水过程的安全与高效。

产品适用于各种气候环境——无论是中东沙漠、高寒冻土,还是海上 FPSO 等苛刻条件,均能稳定可靠运行。

  • 防爆设计,适用于Zone 1区域
  • 可提供交流或直流电源
  • 稳定高压电源输出
  • 适应复杂工况环境

Explosion-Proof Desalter Transformer
AC/DC

As the core of the desalting system, this transformer provides stable, reliable power to ensure safe and efficient crude oil treatment.

It performs in all climates—from desert heat and frozen tundra to offshore FPSO environments.

  • Explosion-proof design for Zone 1
  • AC or DC power supply
  • Stable high-voltage output
  • Adaptable to harsh conditions

电气性能参数
稳定与高效的核心指标

产品在设计中充分考虑到不同应用场景下的电气适配性,确保在各种电网条件下都能保持稳定输出。

核心性能指标涵盖功率、频率、电压范围与调节能力,为系统运行提供可靠保障。

  • 额定功率范围:50–250 kVA
  • 频率:50 Hz
  • 输入电压:380 V AC – 400 V AC
  • 输出电压:10,000 V AC – 40,000 V AC(支持整流)

Electrical Performance
Stable and Efficient Core Metrics

The product is designed for adaptability across different applications, ensuring stable output under varied grid conditions.

Key parameters include power, frequency, voltage range, and regulation capability, providing reliable support for system operation.

  • Rated power: 50–250 kVA
  • Frequency: 50 Hz
  • Input voltage: 380–400 V AC
  • Output voltage: 10,000–40,000 V AC (with rectification)

运行环境与结构参数

本产品在设计上充分考虑多种工况需求,不仅具备良好的环境适应能力,还通过优化的结构保证了长期稳定运行。

无论是在高温、低温、潮湿或粉尘等复杂环境下,设备都能可靠工作,并符合严格的防爆和安全标准,为原油脱盐脱水系统提供坚实保障。

  • 档位:0–5 档可调
  • 周围温度:-55 °C 至 +60 °C
  • 阻抗:30% ~ 100 %
  • 防爆标识:Ex ec oc IIC T5 Gc

Operating Environment and Structure

The product is engineered for diverse operating conditions, with strong environmental adaptability and an optimized structure that ensures long-term stability.

It works reliably in high heat, extreme cold, humidity, or dust, and meets strict explosion-proof and safety standards, providing solid assurance for crude oil desalting systems.

  • Taps: 0–5 adjustable
  • Ambient temperature: -55 °C to +60 °C
  • Impedance: 30%–100%
  • Explosion-proof rating: Ex ec oc IIC T5 Gc
